Description
Model: SCE050
Size (mm)：237x177x63mm
Material：ABS, Metal
Color: Green + Black
12V/ 24V/ 36V/ 48V, 50A PWM Solar Charger
Product Features:
This intelligent compact charger latest PWM control technology, MCU controlled, wider input voltage range, fan-less industrial design and wifi module with cloud server
– 12V/ 24V/ 36V/ 48V, 5 stage battery charging
– Protections:
Reverse polarity protection
Short circuit protection
Over-temperature protection
– Support both Android / iOS
– Real-time monitoring of the input / out level and the performance of the solar controller
– Historical data storage in Cloud server
– Remote control the output load on / off via the mobile APP
Specifications:
– Module Current: 50A PWM
– Max PV input Voltage: 100V
– Max PV Input Power:
12V: 750W,
24V: 1500W,
36V: 2250W,
48V: 3000W
– System Voltage: 12V/ 24V/ 36V/ 48V
– USB Output: 5V/3.4A
– Battery Mode: SLA/ AGM/ LifePO4 (12V only)
– Wifi Module: Optional
– LCD display
